DKM01

DVI USB/ Audio/ RS232 CAT5e KVM Extender

  • Resolution up to 1920x1200@60Hz.
  • Signal extension up to 140M over CAT6.
  • Built in DVI loop-out port at TX unit for an extra local DVI display.
Inquiry

As a manufacturer, we value the profit of our clients and do not have any online store. You can get the unpublished price from us through the inquiry button.

SEE other models
Inquiry

DKM01 is a DVI extender that can not only carry DVI signal but USB, analog audio, RS232 ones using a cost-effective Ethernet cable with transmission distance up to 140M. You can easily control a PC where is far away from you while having an additional DVI monitor along side using the loop-out port at TX unit. It is an ideal solution for industrial, hospital, and education fields.

DVI KVM Extender Cat5e/Cat6 (1920×1200)

DKM01 is a DVI KVM Extender that can transmit DVI, USB, analog audio, and RS232 over a network cable for up to 140 meters. With DKM01, you can control a remote computer while effortlessly outputting to a local DVI monitor. It is ideal for industrial control, healthcare environments, educational setups, and more.

DKM01 - Tx/RX, Front & Rear View

DVI KVM Extender Features

High-Resolution 1920×1200

The DKM01 can provide a maximum DVI resolution of 1920 x 1200 @ 60 Hz, ensuring clear image quality for daily use, monitoring, or viewing to accommodate specific DVI devices such as touch panels.

DVI Local Output

The DKM01 transmitter has a local output port, allowing you to instantly view and configure device settings at the local end.

4-Port USB DVI Extender

Featuring a 4-port USB 2.0 interface, DKM01 simplifies connectivity for peripherals like keyboards, mice, and touchscreens, ensuring efficient and responsive control.

Extended Reach with Repeaters

Seamlessly extend your connectivity by pairing DKM01 with SC&T Network Repeater SR01X. Each additional SR01X extends an extra 120 meters, providing flexibility and scalability in your audio-visual setup.

SC&T KVM Extender Series

If you are looking for KVM extenders for different interfaces, explore the comprehensive SC&T KVM Extender Series. Our diverse selection ensures you find the perfect match for your unique system integration projects.

Model

HKM02BP-4K

HKM02B-4K

HKM02B

VDKM02B

Video Format

HDMI

HDMI

HDMI

VGA/DVI

Resolution

4K@30Hz

4K@30Hz

1080p@60Hz

1080p@60Hz

Audio Embed & Extract

V

V

V

V

IR

V

V

V

V

RS232

V

V

V

V

PoE

V

Fiber Module

V

V

  • Resolution up to 1920x1200@60Hz.
  • Signal extension up to 140M over CAT6.
  • Built in DVI loop-out port at TX unit for an extra local DVI display.

with SR01X
Firmware/Software

Release Date

Ver.

Release Note

File Name

September 15, 2023

V1.0_2309151

Firmware Upgrade
icon

Release Date

September 15, 2023

Ver.

V1.0_2309151

Firmware Upgrade
icon

August 11, 2020

V1.0_2008241

Firmware Upgrade
icon

Release Date

August 11, 2020

Ver.

V1.0_2008241

Firmware Upgrade
icon

June 12, 2019

V1.0_1906121

Firmware Upgrade
icon

Release Date

June 12, 2019

Ver.

V1.0_1906121

Firmware Upgrade
icon
Tutorial Video

Show More
icon

Specification

ITEM NO.

DKM01T

DKM01R

Support

Compliance

HDCP 1.4, USB 2.0, USB 1.1, USB 1.0

Max. Video Resolution

1920 x 1200@60 Hz

Max. Transmission Distance

140M over CAT6 or Greater

Video Bandwidth

10.2 Gbps

Ports & Interfaces

Video Input

1 x DVI-D (Digital Only)

1 x RJ45

Video Output

1 x RJ45

1 x DVI-D (Digital Only)

Video Loop-out

1 x DVI-D (Digital Only)

-

Analog Audio Input

1 x (3.5mm) Stereo Phone Jack (Line In)

1 x (3.5mm) Stereo Phone Jack (Mic In)

Analog Audio Output

1 x 3.5mm Stereo Phone Jack

1 x 3.5mm Stereo Phone Jack

USB Interface

1 x USB 2.0 Type B

4 x USB Type A

RS232 Interface

1 x (3.5mm) Phone Jack

1 x (3.5mm) Phone Jack
